Serial Interface RS422

optoNCDT 1700

Flag hold last value

0x00 0x00 0x00 0x0X 0x0000000X

Synchron mode

0x00 0x00 0x00 0x0X 0x0000000X

Averaging type

0x00 0x00 0x00 0x0X 0x0000000X

Operation mode

0x00 0x00 0x00 0x0X 0x0000000X

Baud rate

0x00 0x00 0x00 0x0X 0x0000000X

ASCII / Binary output

0x00 0x00 0x00 0x0X 0x0000000X

Upper limit

0x00 0x00 0xXX 0xXX 0x0000XXXX

Upper limit

0x00 0x00 0xXX 0xXX 0x0000XXXX

Upper hysteresis value

0x00 0x00 0xXX 0xXX 0x0000XXXX

Lower Hysteresis value

0x00 0x00 0xXX 0xXX 0x0000XXXX

Master value

0x00 0x00 0xXX 0xXX 0x0000XXXX
