Appendix I: SNMP MIB IPn3G “Sample” (Page 11 of 15)
-- COM1 parameter group
COM1_Port_Status OBJECT-TYPE
SYNTAX INTEGER { Disable(0), Enable(1)}
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Port Status: 0 - Disable 1 - Enable"
::= { COM1Config 1 }
COM1_Chanel_Mode OBJECT-TYPE
SYNTAX INTEGER {RS232(0),RS485(1),RS422(2)}
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Channel Mode: A - RS232 B - RS485 C - RS422"
::= { COM1Config 2 }
COM1_Data_Baud_Rate OBJECT-TYPE
SYNTAX INTEGER {B300(0),B600(1),B1200(2),B2400(3), B3600(4),B4800(5),
B7200(6),B9600(7),B14400(8),B19200(9),B28800(10),B38400(11),B57600(12),
B115200(13),B230400(14),B460800(15),B921600(16)}
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Data Baud Rate: 0 - 300 1 - 600 2 - 1200
3 - 2400 4 - 3600 5 - 4800 6 - 7200 7 - 9600 8 - 14400 9 - 19200
10 - 28800 11 - 38400 12 - 57600 13 - 115200 14 - 230400 15-460800,16-961600"
::= { COM1Config 3 }
COM1_Data_Format OBJECT-TYPE
SYNTAX INTEGER {_8N1(0),_8N2(1),_8E1(2),_8O1(3), _7N1(4),
_7N2(5),_7E1(6),_7O1(7),_7E2(8), _7O2(9)}
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Data Format: 0 - 8N1 1 - 8N2 2 - 8E1 3 - 8O1
4 - 7N1 5 - 7N2 6 - 7E1 7 - 7O1 8 - 7E2 9 - 7O2 "
::= { COM1Config 4 }
COM1_Flow_Control OBJECT-TYPE
SYNTAX INTEGER { None(0),Hardware(1),CTSFraming(2)}
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Flow Control: 0 - None 1 - Hardware 2- CTS Framing"
::= { COM1Config 5 }
COM1_PreData_Delay OBJECT-TYPE
SYNTAX DisplayString (SIZE (0..32))
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Pre-frame Delay."
::= { COM1Config 6 }
COM1_PostData_Delay OBJECT-TYPE
SYNTAX DisplayString (SIZE (0..32))
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Post-frame Delay."
::= { COM1Config 7 }
COM1_Data_Mode OBJECT-TYPE
SYNTAX INTEGER {Modbus(0),Transparent(1)}
ACCESS read-write
STATUS mandatory
DESCRIPTION "COM1 Data Mode: 0 - Modbus 1 - Transparent."
::= { COM1Config 8 }
