Example for shifting the image to the X-direction:
Feed
direction
(print
direction)
Printout after the image
shifting to the X-direction.
In this example the value of
the Image X-Position was
increased (NEXT key).
Previous position of the
printout margin (prior to
the image shifting)
Image shifting to the X-direction
