2.5. Printer Components
Fig. 2.5.a Printer Components
Cassette 2
Cassette 1
Control
panel
Power switch
Front cover
(Door F)
Jam access door
(Door A)
Multipurpose
feeder
Standard
output bin
Duplex unit
Cassette 3
(option)
Cassette 4
(option)
