106 Panel Functions
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID 50 A3 - 3 Edition 2.1
Example for shifting the image to the Y-direction:
Feed
direction
(print
direction)
Printout after the image shifting
to the Y-direction.
In this example the value of the
Image Y-Position was increased
(NEXT key).
Previous position of the
printout margin (prior to
the image shifting)
Image shifting to the Y-direction
