OM-278680 Page 24
Gun angle guide
Simulated weld joint
Contact tip-work guide
Travel speed guide
Currently selected
helmet shade
Top status panel can be configured to be hidden
during simulations (see Section 8-2E).
Figure 7-14. Gun/Electrode Positioning Guides Displayed While Welding
Gun angle guide
Figure 7-15. Gun/Electrode Travel Angle Error
