OM-278680 Page 5
4-5. Unit Specifications
Dimensions (L x W x H) Simulator: 17.25 x 9.38 x 21 in. (438 x 238 x 533 mm)
Weight Simulator: 20.7 lb (9.4 kg) AR Welding Helmet: 1.97 lb (0.89 kg)
Simulator and Helmet (including cables): 23.8 lb (10.8 kg)
Input Power 80 to 264 Volts AC, 0.9A (230 VAC) to 1.8A (115 VAC), 50/60 Hz
External VGA Port Resolution External HDMI Port Resolution: 1024 x 768 Pixels
Display Port Resolution: 1024 x 768 Pixels
Resolution during boot-up is 800 x 600 Pixels.
Simulation Modes/Processes Stick (SMAW), MIG (GMAW/FCAW), TIG (GTAW)
Software Version Displayed On System Settings Screen.
Register for free software upgrades at MillerWelds.com/register.
Computer OS: Linux
Processor: i7
RAM: 4GB DDR3L
Graphics Card: NVIDIA GTX 950
60GB Solid State Hard Drive
Main Monitor 9.7 in. integrated LCD monitor, 1024 x 768 resolution
PC Requirements For Installation Of Teacher
Software (See Section 9)
Operating System: Windows 7 (64 bits), Windows 8 (64 bits), Windows 10 (64 bits)
Processor: 2.2 GHz 3 MB
RAM: 4 GB
Display (min): 1366 x 768
Graphic Board: 2GB VRAM Direct X9 compatible graphics card:
NVidia GeForce: 750 or better, or 900 Mobile Series or better
Radeon: HD 6000 series or better, or HD 7000 Mobile series or better
Hard Drive: 1 GB
Supported Welding Processes Stick (SMAW), MIG (GMAW), FCAW, TIG (GTAW)
Parameters Tracked By Cameras MIG: Work Angle, Travel Angle, Travel Speed, Contact Tip To Work Distance (CTWD), Aim
Stick: Work Angle, Travel Angle, Travel Speed, Arc Length, Aim
TIG: Rod Work Angle, Rod Filler Angle, Travel Angle, Travel Speed, Arc Length, Aim, Work
Angle
Supported Joints Bead On Plate, T-Joint, Butt Joint, Lap Joint, Pipe-Plate, Pipe-Pipe
Welding Positions 1F, 2F, 3F, 4F, 1G, 2G, 3G, 4G, 5G, 6G
Workpiece Positions Horizontal, Vertical, Flat, Overhead
Voltage Selection MIG (GMAW and FCAW) 10 − 38 Volts
Amperage (Intensity) Selection Stick (SMAW), MIG (GMAW and FCAW), TIG (GTAW): 50 − 425 Amps
Polarity Selection DCEP, DCEN, AC
Shielding Gas Selection CO2, Argon-O2, Argon-CO2, And Mixtures
Wire Speed Selection MIG (GMAW and FCAW): 50 - 1000 ipm (1.27 − 25.4 m/min)
Base Material Selection Carbon Steel, Stainless Steel, Aluminum
Workpiece Thickness Selection 1/8, 1/4, 3/8 in. (3.2, 6.4, 9.5 mm)
Stick Electrode Selection E7018, E6010, E6013
Stick Electrode Diameter Selection 1/8, 3/32, 5/32 in. (2.50, 3.25, 4.00 mm)
Wire Diameter Selection Solid Wire: 0.030, 0.035, 0.045 in. (0.8, 1.0, 1.2 mm)
Filler Rod Selection 5/64, 3/32 in. (2.0 And 2.4 mm)
Real Time Guide Parameters On-Screen Help Guides Provide Corrective Feedback To User During Simulation
Teacher Software Standalone Application
Helmet Miller Black Infinity Helmet With Premium Headgear. Includes Integrated 4.8 in. LCD dis-
play (1024 x 600), and integrated speakers.
MIG Guns/TIG Torches Miller Brand
Stick Electrode And TIG Filler Rod Markers AR Marker Attachment
Measurements Global Setting Displays Measurements In Standard (Imperial) Or Metric
Languages English, French, Spanish
4-6. Software Licensing Agreement
The End User License Agreement and any third-party notices and terms and conditions pertaining to third-party software can be found at
https://www
.millerwelds.com/eula
and are incorporated by reference herein.
To Next Page
