2.1.2.3 Main Unit (Left View)

Part Description

Mounting rail

The mounting rail is a standard accessory arm for

installing the monitor and other devices. Two mounting

rails are provided on the left and right of the machine.

High-flow O2 outlet

The outlet is used to output high-flow O2.
