Part Description
The module slot is used to install and identify the AG
module described in this manual.
Canada：
The module slot is used to install and identify the NMT,
AG, and BIS module described in this manual.
regulating knob
You can rotate the knob clockwise or counterclockwise
to adjust the flow in the AGSS, until the float on the
status display is between the Min and Max scales.
A sample gas return port is provided for the gas module.
Auxiliary high-pressure
O2 outlet
The outlet is used to connect to an external device, for
example, a jet ventilator.
O2 sensor door cover
switch
The switch is used to open the O2 sensor door cover.
The handle can bear maximum force of 10 kgf (22 lbf).
The handle is only used for disassembling the breathing
system, but not for pushing/pulling/lifting the anesthesia
The handle is used for pushing/pulling/turning the
anesthesia machine. It can bear maximum force of 80 kgf
