2-14
Part Description
The absorber bypass assembly is used to retain the
pressure in the breathing circuit when you replace the
sodalime in the CO2 absorber canister.
The water collection cup is used to collect condensate
from the breathing system. It must be periodically
The CO2 absorber canister is a container for holding
the CO2 absorbent (bulk or Pre-pak CO2 absorbent).
The canister lock is a lever locking mechanism for
locking (in the horizontal position)/unlocking (in the
vertical position) the canister.
2.1.2.7 Negative Pressure Suction Device
Part Description
Overfill protection is used to prevent overfill of waste
liquid, so as to ensure pipeline safety.
The filter is used to filter out moisture and impurities.
The liquid collection bottle is used to collect effusions,
hematocele, pus, and other contaminants from the
The gauge is used to indicate the negative pressure.
