Mindray A8 Service Manual

2-53
No.
Description
No.
Description
1.1
Filter
13.2
2/3 Switch-Over Valve
1.2
Check Valve
13.3
Normally Opened Valve
1.3
Pressure Switch
13.4
2/3 Switch-Over Valve
1.4
Pressure Relief Valve
13.5
Normally Closed Valve
1.5
Pressure Regulating Valve
13.6
Normally Closed Valve
1.6
Cylinder Pressure Gauge
13.7
2/3 Switch-Over Valve
1.7
Electronic Pressure Sensor of Cylinder
13.8
2/3 Switch-Over Valve
1.8
Pressure Regulating Valve of Cylinder
13.9
Check Valve
1.9
Check Valve of Cylinder
13.10
Check Valve
1.12
Electronic Pressure Sensor of Pipeline
13.11
2/3 Switch-Over Valve
2.1
Filter
13.12
Normally Closed Valve
2.2
Electronic Pressure Sensor of Pipeline
13.13
Normally Closed Valve
2.3
Pressure Relief Valve
13.14
2/3 Switch-Over Valve
2.4
Check Valve
13.15
Pneumatic Self-Lock Valve
2.5
Pressure Regulating Valve
13.16
2/3 Switch-Over Valve
2.6
Cylinder Pressure Gauge
13.17
Pneumatic Self-Lock Valve
2.7
Electronic Pressure Sensor of Cylinder
14.1
Filling hole
2.8
Pressure Regulating Valve of Cylinder
14.2
Driving gas outlet
2.9
Check Valve
14.3
Driving gas inlet
3.1
Filter
14.4
Filter
3.2
Electronic Pressure Sensor of Pipeline
14.5
Filter
3.3
Pressure Relief Valve
14.6
Switch-cover-linked pressure supply
and relief valve
3.4
Check Valve
14.7
Pressure sensor
3.5
Cylinder Pressure Gauge
14.8
Normally-closed switch valve
3.6
Electronic Pressure Sensor of Cylinder
14.9
Capacitive liquid level sensor
3.7
Pressure Regulating Valve of Cylinder
14.10
Ultrasonic liquid level sensor
3.8
Check Valve
14.11
Filter
4.1
Overfill Protector
14.12
Normally-closed switch valve
4.2
Negative Pressure Gauge
14.13
Spraying control valve
4.3
Negative Pressure Regulating Switch
14.14
Infrared counter
4.4
Mode Selector Switch
14.15
Fresh Gas Inlet
