Mindray A8 Service Manual

2-54
5.8
Float Flowmeter(0-60LPM)
14.16
Anesthetic mixing chamber
5.9
Check Valve
14.17
Mixed gas outlet
5.10
Differential Pressure Gauge
15.1
Internal AG
5.11
Proportional Valve
15.2
2/3 Switch-Over Valve
5.12
Pilot Normally Closed Valve
15.3
2/3 Switch-Over Valve
5.13
Pilot 2/3 Switch-Over Valve
15.4
Self-sealing Sampling Tube
5.14
Check Valve
15.5
External AG
5.15
Differential Pressure Gauge
16.1
Pressure Sensor
5.16
Proportional Valve
16.2
2/3 Switch-Over Valve
5.17
Pilot Normally Closed Valve
17.1
Flow Restrictor
6
High-Pressure O2 Output
17.2
ACGO Switch
7
O2 Flush
17.3
11kPa (112 cmH
2
O) Pressure Relief
Valve
8
System Switch
17.4
ACGO Port
9.1
Pilot-Operated Valve of Manual/Auto
Switch
18.1
Check Valve
9.2
Pilot-Operated Valve of AGSS On/Off
18.2
Airway Pressure Gauge
10.1
Filter
18.3
O2 Sensor
10.2
Pressure Regulating Valve
18.4
Differential Pressure Gauge of
Inspiration
10.3
Proportional Valve
18.5
2/3 Switch-Over Valve
10.4
Flow Sensor
18.6
2/3 Switch-Over Valve
10.5
Filter
18.7
Inspiration Flow Sensor
10.6
Normally-Closed Switch Valve
18.8
Pressure Sensor
10.7
Pressure Switch
18.9
Inspiratory Port
10.8
Proportional Valve
18.10
Expiratory Port
10.9
Flow Restrictor
18.11
Differential Pressure Gauge of
Expiration
11.1
Check Valve
18.12
2/3 Switch-Over Valve
11.2
O2 Needle Valve
18.13
Expiration Flow Sensor
11.3
Check Valve
18.14
Watertrap
11.4
Air Needle Valve
18.15
Check Valve
11.5
Float Flowmeter (0-15LPM)
18.16
Self-Sealing Sampling Tube
11.6
Normally-Open Switch Valve
18.17
Bypass
12.1
Filter
18.18
CO2 Absorber Canister
12.2
Normally-Closed Switch Valve
18.19
Check Valve
