15. Interface specifications
MiR100 Hook User Guide (en) 10/2020 - v.3.0 ©Copyright 2016-2020: Mobile Industrial Robots A/S. 185
15. Interface specifications
This section describes the specifications of the top application interfaces.
NOTICE
Read Safety on page23 before using the electrical interface.
When MiR Hook 100 is mounted to MiR100, the electrical top interfaces are
no longer accessible.
15.1 Application interface
The application interface plug is a NEUTRIK XLR panel-mount connector with 4 contacts
(receptable).
Figure 15.1. Application interface.
