6
FUNCTIONS
6.13 Execution Time Measurement
6.13.3 Scan time measurement
6
- 78
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication with
Intelligent Function
Module
8
Parameters
• The scan time measurement range is specified.
(The specified area is highlighted.)
• Choose [Online] [Monitor] [Scan time measurement] to open "Scan time
Measurement" dialog box.
• Click on the button.
Diagram 6.48 Measurement range designation
Diagram 6.49 Scan time measurement window
Y20
M0
50
Y21
52
Y22
104
106
END
M1
M2
Start
To Next Page
