6
FUNCTIONS
6.26 Device Initial Value
6
- 162
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication with
Intelligent Function
Module
8
Parameters
• At the "PLC file" tab screen in the "(PLC) Parameter" dialog box, designate the
name of the file where the device initial value data is to be stored.
1) For Basic model QCPU
Set Device initial values to "Use" in the PLC file setting of the PLC parameter
dialog box.
2) For High Performance model QCPU, Process CPU, Redundant CPU
Set the file name that stores the used device initial value data in the PLC file
setting of the PLC parameter dialog box.
• Write the device initial value data and parameter settings to the CPU module.
Diagram 6.93 PLC file screen (for High Performance model QCPU)
To Next Page
