9.10 Interrupt pointer (I)
9
DEVICE EXPLANATION
(3) Interrupt factors
Table9.17 indicates the interrupt factors of the interrupt pointers.
Note20
: Available : Some interrupt pointers unavailable : N/A
* 1 : Refer to the following manual for the available interrupt modules.
QCPU User's Manual (Hardware Design, Maintenance and Inspection)
* 2 : The interrupt pointer I49 (high-speed interrupt function dedicated pointer) is available for the
QnHCPU only.
* 3 : The Q02CPU cannot use the interrupt pointer I49 (high-speed interrupt function dedicated
pointer).
* 4 : The interrupt pointers I33, I40, I41 are available for the Redundant CPU only.
* 5 : For the error to which the error-time operation mode can be set in the PLC RAS setting of the PLC
parameter dialog box, an interrupt is executed only when the setting is "Continue".
* 6 : The following table shows the the number in the "Applicable CPU module" field and the
corresponding CPU module
POINT
To use the intelligent function module interrupt ( Section 6.23), the intelligent
function module setting (interrupt points setting) is required at the "PLC system"
tab screen in the "(PLC) Parameter" dialog box.
Table9.17 Interrupt factor classification
Interrupt factor Interrupt pointer No. Description
Applicable CPU module
*6
1) 2) 3) 4)
Interrupt module
*1
factor
Note9.20
I0 to 15
Interrupt input from the interrupt module
*1
Sequence start generator
module factor
I16 to 27
Interrupt from the special function module that
can make the CPU module start an interrupt.
(Except QI60 and A1SI61)
Internal timer factor I28 to 31, I49
Fixed scan interrupt by the internal timer of the
CPU module.
*2 *2 *3 *2
Error factor
*5
I32 to 41
Interrupt made by occurrence of error that
continues sequence program operation.
*4 *4
Intelligent function module
factor
I50 to 255
(I50 to 127 for Basic model
QCPU)
Interrupt from the intelligent function module.
Note20
Table9.18 Applicable CPU module
No. CPU module
1) Basic model QCPU
2) High Performance model QCPU
3) Process CPU
4) Redundant CPU
High
Performance
Note9.20
When using the interrupt module with the High Performance model QCPU, check the versions of
the CPU module and GX Developer. ( Appendix 3.2)
Note9.20
High
Performance
