Mitsubishi Q02CPU User Manual

10
DEVICE EXPLANATION
10 - 3
10.1 Device List
(2) High Performance model QCPU, Process CPU, Redundant CPU,
Universal model QCPU
(Continued on next page)
Table10.2 Device List
Class Type Device Name
Default Values Parameter
Designated
Setting
Range
Reference
Section
Number of
Points
Range Used
Internal
user
devices
Bit
devices
Input
8192 X0 to 1FFF Hexadecimal
Changeable
within
29k words.
*3
Section 10.2.1
Output
*3
8192 Y0 to 1FFF Hexadecimal Section 10.2.2
Internal relay 8192 M0 to 8191 Decimal Section 10.2.3
Latch relay 8192 L0 to 8191 Decimal Section 10.2.4
Annunciator 2048 F0 to 2047 Decimal Section 10.2.5
Edge relay 2048 V0 to 2047 Decimal Section 10.2.6
Step relay 8192 S0 to 511 / block Decimal Section 10.2.9
Link special relay 2048 SB0 to 7FF Hexadecimal Section 10.2.8
Link relay 8192 B0 to 1FFF Hexadecimal Section 10.2.7
Word
devices
Timer
*1
2048 T0 to 2047 Decimal
Section
10.2.10
Retentive timer
*1
0 (ST0 to 2047) Decimal
Counter
*1
1024 C0 to 1023 Decimal
Section
10.2.11
Data register 12288 D0 to 12287 Decimal
Section
10.2.12
Link register 8192 W0 to 1FFF Hexadecimal
Section
10.2.13
Link special register 2048 SW0 to 7FF Hexadecimal
Section
10.2.14
Internal
system
devices
Bit
devices
Function input 5 FX0 to F Hexadecimal
Unchangeable
Section 10.3.1
Function output 5 FY0 to F Hexadecimal Section 10.3.1
Special relay 2048 SM0 to 2047 Decimal Section 10.3.2
Word
devices
Function register 5 FD0 to 4 Decimal Section 10.3.1
Special register 2048 SD0 to 2047 Decimal Section 10.3.3
Link direct
devices
Bit
device
Link input 8192 Jn\X0 to 1FFF Hexadecimal
Unchangeable Section 10.4
Link output 8192 Jn\Y0 to 1FFF Hexadecimal
Link relay 16384 Jn\B0 to 3FFF Hexadecimal
Link special relay 512 Jn\SB0 to 1FF Hexadecimal
Word
device
Link register 16384
Jn\W0 to 3FFF
Hexadecimal
Link special register 512 Jn\SW0 to 1FF Hexadecimal
Module
access
devices
Word
device
Intelligent function
module device
65536
Un\G0 to 65535
*2
Decimal Unchangeable
Section 10.5
Common device for
multiple CPU
*4
4096
(14336)
*5
U3En\G0 to 4095
(U3En\G10000 to
24335)
*6
Decimal Changeable
