MKS 937B - Figure 8-5 Buffered Analog Output for a 345 Pirani Gauge

MKS 937B Operation Manual
76
Buffered Pirani Analog Output
(Series 315 & 345)
Pressure, Torr
10
-4
10
-3
10
-2
10
-1
10
0
10
1
10
2
10
3
Output Voltage, V
0
1
2
3
4
5
6
7
8
9
10
He
N
2
Ar
Figure 8-5 Buffered analog output for a 345 Pirani gauge.
