Setting Up
1. If the PPC 300 II  is to be used together with the fixture for package restraining  the
two units must be assembled using the screws
.
2. Connect the unit’s air supply (Feed) and pressure measurement (Sense) hoses  to the
device.
3. Connect external air supply hose(s)  (4-6 Bar) to each of the “Air Supply 4-6 Bar” and
“Control Lower Bar” inlets.
