26 User Guide EN Dansensor® Lippke® 5000
P/N 380419-C
05/2022
Adjusting the restraining height (PPC 300 II)
The package restraining fixture for the PPC 300 II can be adjusted to various package
restraining heights.
The restraining height is achieved by adjusting the distance between the two plates and
.
Use the nuts and finger nuts to adjust the position of the lower plate , then use the
nuts
and finger nuts to adjust and lock the position of the side bars and thereby the
position of the upper plate
.
NOTE! Make sure to adjust the side bars to the same height so that the upper
plate can move freely.
