42 User Guide EN Dansensor® Lippke® 5000
P/N 380419-C
05/2022
Package Connection Select whether or not testing will be performed with
combined or separate Feed- and Sense needles.
- Select “Combined Feed/Sense” if you are using the
test head or the “Combined” type hand-held needle.
- Select “Separate Feed/Sense” for all other types of
needles and accessories.
The current setting is indicated with an icon on the test
screen - see
"The Test screen" on page 61 for details.
Package Volume (Vol.) Headspace volume for a filled package.
Prefill Pressure (P1) If a package for example changes shape when it is filled,
then set the pre-fill pressure so that this will happen
during the pre-fill time.
This avoids false burst detections.
Max. Pressure (Pmax) The maximum pressure the package is filled to. If the
package does not burst, the test is stopped when the
max. pressure is reached.
Limit, Min. Burst Pressure (P2) Lower limit for an approved test. The package should
burst above this limit.
Limit, Max. Burst Pressure (P3) Upper limit for an approved test. The package should
burst below this limit.
Inflation Rate (P/T) Linear pressure increase rate from when pre-fill pressure
is reached until the package bursts or the max. pressure
is reached.
Burst Detection Limit (L) If a package for some reason expands suddenly during
the test, this will result in a pressure drop that could be
mistaken for a burst of the package.
Use this parameter to specify the max. accepted
pressure drop.
Custom Fields * Select if one or more of the 4 custom fields are required
for the current workflow - see
"Custom Fields" on page 95
for details.
