Moeller DF51 - Maintenance and inspection; Electrocution hazard

10/05 AWB8230-1541GB
Holding register (word
variable)
183
151E A295 Acceleration time, frequency
for changeover from ramp
time 1 to ramp time 2
(second parameter set)
rw 0.0 – 400 Hz 0.1 [Hz]
151F A296 Reserved
rw – –
1520 A296 Deceleration time,
frequency for changeover
from ramp time 1 to ramp
time 2 (second parameter
set)
rw 0.0 – 400 Hz
1521 – Reserved
rw – –
…
1525
1526 b212 Thermal overload, tripping
current (second parameter
set)
rw 0.2 – 1.2 x Ie [A]
0.2 – 1.2 x Ie [A]
0.01 [%]
1527 b213 Thermal overload,
characteristic (torque curve)
(second parameter set)
rw 00: Reduced torque 1 –
01: Constant torque
02: Reduced torque 2
1528 b221 Motor current limitation,
function (second parameter
set)
rw 00: OFF, disabled –
01: ON, enabled in acceleration phase and at
constant speed
02: Enabled only at constant speed
1529 b222 Motor current limitation,
tripping current (second
parameter set)
rw 0.2 – 1.5 x Ie [A]
Default, dependent on frequency inverter’s rated
current (Ie)
0.01 [%]
152A b223 Motor current limitation,
deceleration time constant
(second parameter set)
rw 0.1 – 3000 s 0.1
152B b228 Motor current limitation,
limit current selection
(second parameter set)
rw 00: Value of PNU b022 –
01: Analog input O-L
152C – Reserved
rw – –
…
1530
1531 C201 Digital input 1 – function
(second parameter set)
rw Values a PNU C001 (1103
hex
) –
1532 C202 Digital input 2 – function
(second parameter set)
rw Values a PNU C001 (1103
hex
) –
1533 C203 Digital input 3 – function
(second parameter set)
rw Values a PNU C001 (1103
hex
) –
1534 C204 Digital input 4 – function
(second parameter set)
rw Values a PNU C001 (1103
hex
) –
1535 C205 Digital input 5 – function
(second parameter set)
rw Values a PNU C001 (1103
hex
) –
1536 C206 Digital input 6 – function
(second parameter set)
DV51 only
rw Values a PNU C001 (1103
hex
) –
Holding
register
Function
code
Name Access
rights
Value range Manipulated
variable
hex
