6-37
iControl Messages
iControl AC
6
Fire Service In-car Recall Operation
Description: A car on in-car firefighter operation is being recalled to the designated fire recall floor.
Car Reaction: Car proceeds to designated fire recall floor. Once at recall floor, door operation is according to
user-defined door operation under fire recall operation.
Troubleshooting:
1. Check the in-car firefighter switch status and Fire II operation user settings.
Fire Service Recall Alternate, Fire Recall Alternate, Fire Recall Alt.
Description: Fire recall to the alternate fire floor has been initiated.
Car Reaction: Car proceeds to user-defined alternate fire recall floor. Once at recall floor, door operation is
according to user-defined door operation under fire recall operation.
Troubleshooting:
1. If in error, inspect the fire sensor and switch inputs and connections.
2. Related Inputs: Smoke sensors and fire recall switches as indicated on the job prints.
Fire Service Recall Main, Fire Recall Main, Fire Recall Main
Description: Fire recall to the main fire floor has been initiated.
Car Reaction: Car proceeds to the user-defined main fire recall floor. Once at the recall floor, door operation
is according to the user-defined door operation under fire recall operation.
Troubleshooting:
1. If in error, inspect the fire sensor and switch inputs and connections.
2. Related Inputs: Smoke sensors and fire recall switches as indicated on the job prints.
Fire Service Recall Deactivated
Description: Fire service recall operation has been deactivated.
Car Reaction: Car returns to its prevailing mode of operation.
Troubleshooting: NA
Flood Operation Activated, FLOOD OPERATION
Description: Flood operation has been activated via system command or hardware switch.
Car Reaction: A car in the flood zone area moves immediately to a floor outside the flood zone. The car will
no longer service the floors in the flood zone until Flood Operation is deactivated.
Troubleshooting: Check the flood zone switch and the user interface command.
Flood Operation Deactivated
Description: Flood operation has been deactivated.
Car Reaction: The car will service all eligible floors.
Floor Heat Detectors Activated, FLOOR HEAT DETECTORS
Description: One or more floor heat detector inputs activated. Fire warning light will flash until all heat detec-
tors have been reset. The fire-warning buzzer will sound until the car is shutdown at a floor.
Car Reaction: A car that is parked at a floor will open its doors and shut down. A car in motion will proceed in
the current direction to next available floor where heat detector is not tripped. If all heat detectors in current
direction are tripped, car will reverse direction and proceed to first floor where heat detector is not tripped. If
again all heat detectors are tripped, car shall proceed to main fire recall floor unless car is also on Fire Ser-
vice, in which case car will proceed to appropriate fire recall floor. Once car is stopped at a floor it shall auto-
matically open its doors and shut down. Then, if machine room or hoistway heat detectors are active, a
signal is provided to disconnect main power line and activate sprinklers where available.
Floor Heat Detectors Deactivated
Description: All floor heat detector inputs are deactivated.
Car Reaction: The car is allowed to run.
Table 6.3 iControl Messages
