6-87
iControl Circuit Board Quick References
iControl AC
6
Table 6.1 ICE-CTP-2 Board Connections
Terminal Description
1Common
DLSP Door Logic Supply (See job prints for source level)
2120VAC
DOF Door Open Function output (active level =DLSP)
DBF Door Boost Function output (active level =DLSP)
DCF Door Close Function output (active level =DLSP)
NUDG Door Nudge output (active level =DLSP)
SP1 Spare Input (120VAC signal level)
SP2 Spare Input (120VAC signal level)
SP3 Spare Input (120VAC signal level)
IMP_RST Reset from ICE-IMP board
SE (Door) Safe Edge Input (120VAC signal level)
PHE Photo Eye input (120VAC signal level)
DOL Door Open Limit input (120VAC signal level)
DCL Door Close Limit input (120VAC signal level)
DPM Door Position Monitor input (120VAC signal level)
ICTD Cartop inspection down button (110VDC= switch closed)
ICTU Cartop inspection up button (110VDC= switch closed)
INCT Cartop inspection switch active (110VDC= switch closed)
GS Gate Switch input (110VDC= switch closed)
GS-R Gate Switch Rear (110VDC= switch closed)
ULM-R Up Level Marker Rear output (110VDC= output active)
DZ-R Door Zone Rear (110VDC= output active)
DLM-R Down Level Marker Rear (110VDC= output active)
ULM Up Level Marker (110VDC= output active)
DZ Door Zone (110VDC= output active)
DLM Down Level Marker (110VDC= output active)
1Common
2120VAC
3110VDC
SCT1 Cartop Safety Contact 1 (110VDC= contact closed)
SCT2 Cartop Safety Contact 2 (110VDC= contact closed)
