Motorola Solutions AP-6511 Access Point System Reference Guide
2-6
2.2.4 Status Icons
Web UI Overview
These icons define device status, operations on the wireless controller, or any other action that requires a
status being returned to the user.
2.2.5 Configurable Objects
Web UI Overview
These icons define configurable items within the UI.
Fatal Error – States there is an error causing a managed device to stop
functioning.
Error – Indicates an error exits requiring intervention. An action has failed, but
the error is not system wide.
Warning – States a particular action has completed, but some errors were
detected that did not stop the process from completing. Intervention might
still be required to resolve subsequent warnings.
Success – Indicates everything is well within the network or a process has
completed successfully without error.
Information – This icon always precedes information displayed to the user.
This may either be a message displaying progress for a particular process, or
may just be a message from the system.
Device Configuration – Represents a configuration file applicable to a device
category.
Adoption Policy – Represents an adoption policy. Adoption policies are a set
of configuration parameters that define how APs and wireless clients are
adopted. An AP-6511 Adoption Policy only applies to other AP-6511 models.
Wireless LANs – States an action impacting a WLAN has occurred.
WLAN QoS Policy – States a quality of service (QoS) policy configuration has
been impacted.
