Motorola Solutions AP-6511 Access Point System Reference Guide
13-62
13.3.16.2 NTP Association
Network Time
To view the Network Time statistics of an access point:
1. Select the Statistics menu from the Web UI.
2. Select the System tab and then select the Access Point node.
3. Select Network Time.
4. Select the NTP Association tab.
Figure 13-40 Access Point - Network Time Association screen
The NTP Association screen displays the following:
Delay Time Displays the round-trip delay (in seconds) for SNTP broadcasts between the
SNTP server and the Access Point.
Display Displays the time difference between the peer NTP server and the Access
Point’s clock.
Offset Displays the calculated offset between the Access Point and the SNTP server.
The Access Point adjusts its clock to match the server’s time value. The offset
gravitates towards zero overtime, but never completely reduces its offset to
zero.
Poll Displays the maximum interval between successive messages in seconds to
the nearest power of two.
Reach Displays the status of the last eight SNTP messages. If an SNTP packet is
lost, the lost packet is tracked over the next eight SNTP messages.
Reference IP
Address
Displays the address of the time source the Access Point is synchronized to.
Server IP
Address
Displays the numerical IP address of the SNTP resource (server) providing
SNTP updates to the Access Point.
