Profile Configuration
7-29
4. Set the following parameters for IP DSCP mappings for untagged frames:
5. Use the spinner controls within the 802.1p Priority field for each DSCP row to change its priority value.
6. Select the OK button located at the bottom right of the screen to save the changes. Select Reset to revert
to the last saved configuration.
7.3.4 Static Routes
Profile Network Configuration
Use the Static Routes screen to set Destination IP and Gateway addresses enabling assignment of static
IP addresses for requesting clients without creating numerous host pools with manual bindings. This
eliminates the need for a long configuration file and reduces the resource space required to maintain address
pools.
To create static routes:
1. Select Configuration > Profiles > Network.
2. Expand the Network menu to display its submenu options.
3. Select Static Routes.
DSCP Lists the DSCP value as a 6-bit parameter in the header of every IP packet used
for packet classification.
802.1p Priority Assign a 802.1p priority as a 3-bit IP precedence value in the Type of Service
field of the IP header used to set the priority. The valid values for this field are
0-7. Up to 64 entries are permitted. The priority values are:
0 – Best Effort
1 – Background
2 – Spare
3 – Excellent Effort
4 – Controlled Load
5 – Video
6 – Voice
7 – Network Control
