Device Configuration
5-75
15.Set or override the following to define the Dynamic NAT configuration:
16.Select OK to save the changes or overrides made to the dynamic NAT configuration. Select Reset to
revert to the last saved configuration.
5.4.4 Overriding a Profile’s Services Configuration
A profile can contain specific guest access (captive portal), DHCP server and RADIUS server configurations.
These access, IP assignment and user authorization resources can be defined uniquely as profile
requirements dictate.
To define or override a profile’s services configuration:
1. Select Devices from the Configuration tab.
2. Select a target device (by double-clicking it) from amongst those displayed within the Device
Configuration screen.
Devices can also be selected directly from the Device Browser in the lower, left-hand, side of the UI.
3. Select Profile Overrides from the Device menu to expand it into sub menu options.
4. Select Services.
Source List ACL
Use the drop-down menu to select an ACL name to define the packet
selection criteria for NAT. NAT is applied only on packets which match a
rule defined in the access-list. These addresses (once translated) will not
be exposed to the outside world when the translation address is used to
interact with the remote destination.
Network
Select Inside or Outside NAT as the network direction for the dynamic NAT
configuration. Inside is the default setting.
Interface
Use the drop-down menu to select the VLAN (between 1 - 4094) used as
the communication medium between the source and destination points
within the NAT configuration. Ensure the VLAN selected adequately
supports the intended network traffic within the NAT supported
configuration. VLAN1 is available by default.
Overload Type
Select the radio button of Overload Type used with the listed IP ACL rule.
Options include NAT Pool, One Global Address and Interface IP Address.
Interface IP Address is the default setting.
NAT Pool
Provide the name of an existing NAT pool for use with the dynamic NAT
configuration.
Overload IP
If One Global IP Address is selected as the Overload Type, define an IP
address used a filter address for the IP ACL rule.
NOTE: A blue override icon (to the left of a parameter) defines the parameter as having
an override applied. To revert the override back to its original profile setting, select the
override icon to display an Action pop-up. Select the Remove Override checkbox to
revert the override to its original setting for this profile.
