Statistics
13-17
13.2.6 SMART RF
RF Domain
When invoked by an administrator, Self-Monitoring At Run Time (Smart RF) instructs radios to change to a
specific channel and begin beaconing using the maximum available transmit power. Within a well-planned
deployment, any associated radio should be reachable by at least one other radio. Smart RF records signals
received from its neighbors as well as signals from external, un-managed radios. AP-to-AP distance is
recorded in terms of signal attenuation. The information from external radios is used during channel
assignment to minimize interference.
To view Smart RF statistics:
1. Select the Statistics menu from the Web UI.
2. Select the RF Domain tab from the left navigation pane and then select the RF Domain node.
3. Select SMART RF.
Figure 13-10 SMART RF screen
This screen provides the following information:
Tx Dropped Displays the total number of transmitted packets which have been dropped
by each radio. This includes all user data as well as any management
overhead packets that were dropped.
Rx Errors Displays the total number of received packets which contained errors for each
radio.
AP MAC Address Displays the MAC address of the AP (the device MAC address printed on the
unit).
MAC Address This is the radio’s recognized MAC address when adopted.
