Motorola Solutions AP-6511 Access Point System Reference Guide
13-48
13.3.11.2 DHCP Networks
Network
To view a network’s DHCP Networks:
1. Select the Statistics menu from the Web UI.
2. Select the System tab and then select the Access Point node.
3. Select Network > DHCP Networks.
The DHCP Networks screen displays the following:
13.3.12 Firewall
Access Point Statistics
A firewall is a part of a computer system or network designed to block unauthorized access while permitting
authorized communications. It’s a device or set of devices configured to permit or deny computer applications
based on a set of rules.
This screen is partitioned into the following:
Packet Flows
IP Firewall Rules
MAC Firewall Rules
NAT Translations
DHCP Snooping
13.3.12.1 Packet Flows
Firewall
The Packet Flows screen displays a bar graph for the different packet types flowed through the Access Point.
Use this information to assess the traffic patterns supported by the Access Point.
The Total Active Flows graph displays the total number of flows supported. Other bar graphs display for
each individual packet type.
To view the packet flows statistics:
1. Select the Statistics menu from the Web UI.
2. Select the System tab and then select the Access Point node.
3. Expand the Firewall menu to reveal its sub menu options.
4. Select Packet Flows.
Name Displays the name of the DHCP pool.
Subnet Address Displays the subnet addresses of the DHCP Pool.
Used Addresses
Number of addresses that have already been leased.
Total Addresses Total available addresses that can be leased to clients.
