Motorola Solutions AP-6511 Access Point System Reference Guide
13-4
This area displays the following information:
The Utilization Index field displays a table with a list of RF Domain with the most effective resource
utilization. Utilization is dependent on the number of devices connected to the RF Domain.
The Utilization Index field also displays packet transmit and receive data:
The Wireless Security field defines device security in each RF domain. The Average Threat Index is an
integer value indicating the threat to the system as a whole.
The Wireless Security field also displays a table that displays the top 5 in terms of threat perception.
Worst 5 Displays the lowest quality indices in the wireless network. The values can be
interpreted as:
• 0-50 – Poor quality
• 50-75 – Medium quality
• 75-100 – Good quality
RF Domain Displays the name of the RF domain.
Best 5 Utilization index is a measure of how efficiently the domain is utilized. This
value is defined as a percentage of current throughput relative to the
maximum possible throughput. The values are:
• 0-20 – Very low utilization
• 20-40 – Low utilization
• 40-60 – Moderate utilization
• 60 and above – High utilization
RF Domain Displays the name of the RF Domain.
Client Count Displays the number of wireless clients associated with the RF Domain.
Total Packets Displays the total number of data packets transmitted and received by the
system.
Total Bcast/Mcast
Packets
Displays the total number of broadcast/multicast packets processed by the
system.
Total Management
Packets
Displays the total number of management packets processed by the system.
Top 5 Displays the threat perception value. This value can be interpreted as:
• 0-2 – Low threat level
• 3-4 – Moderate threat level
• 5 – High threat level
RF Domain Displays the name of the RF Domain for which the threat level is displayed.
Concern Describes the top most threat to the devices in this RF domain.
