Device Configuration
5-17
5. Define the following configuration parameters required for the Import of the key:
6. Select OK to generate the RSA key. Select Cancel to revert the screen to its last saved configuration.
7. To optionally import a CA certificate, select the Import button from the RSA Keys screen.
Figure 5-11 Certificate Management - Import New RSA Key screen
8. Define the following configuration parameters required for the Import of the RSA key:
Key Name Enter the 32 character maximum name assigned to the RSA key.
Key Size Use the spinner control to set the size of the key (between 1,024 - 2,048 bits).
Motorola Solutions recommends leaving this value at the default setting of
1024 to ensure optimum functionality.
Key Name Enter the 32 character maximum name assigned to the RSA key.
Key Passphrase Define the key used by both the AP-6511 and the server (or repository) of the
target RSA key. Select the Show textbox to expose the actual characters used
in the passphrase. Leaving the Show checkbox unselected displays the
passphrase as a series of asterisks “*”.
URL Provide the complete URL to the location of the RSA key. If needed, select
Advanced to expand the dialog to display network address information to the
location of the target key. The number of additional fields that populate the
screen is also dependent on the selected protocol.
