VJ-1624X/1624WX/1924WX OPERATION MANUAL Before using
3.6 Print quality adjustment 155
• While “Warming Up” is displayed, do not touch Platen and Media guide.
They become very hot and you could burn yourself.
You can start printing during warming up.
4.4.7 Starting printing during warming up (VJ-1624X only)
• An adjust print pattern is printed.
6 micro adjust print patterns (A to F) are printed. Enter the adjusted values for each of them.
(VJ-1624X starts printing after warming up is complete.)
• For the Adjust print pattern, the same petterns will be printed repeatedly on both sides and center
of the media.
Pattern name
1234567
1234567
Print information
Bi dir
Low H.Height
normal speed
small drop family
Bi dir
Low H.Height
normal speed
large drop family
To Next Page
