4 Handling the printer VJ-1624X/1624WX/1924WX OPERATION MANUAL
172 4.2 Media
2. Change the head height by moving Head height adjustment lever (orange).
• Do not raise Head height adjustment lever higher than the following position.
Doing so may damage the printer.
(VJ-1624X)
(VJ-1624WX/1924WX)
• High lamp on Operation panel lights up in green.
No. Name
1 Head height adjustment lever
No. Name
1 Head height adjustment lever
To Next Page
