VJ-1624X/1624WX/1924WX OPERATION MANUAL 2 Product overview
2.1 Names of parts and functions 29
3 Front cover Used to prevent the user from coming in contact with the driving mechanism during
the printer operation.
Opened and closed when media is loaded or jammed.
It is normally closed.
4 Stand Used when installing the printer on a flat floor.
5 Media guide Used to feed the media smoothly when loading or printing on the media.
• Heater (After heater) to dry ink is installed inside VJ-1624X.
• VJ-1624WX/1924WX is not equipped with Heaters.
6 Platen Installed inside of Front cover.
• Heater (Platen heater) to dry ink is installed inside VJ-1624X.
• VJ-1624WX/1924WX is not equipped with Heaters.
7 Pressurizing rollers Installed inside of Front cover.
Press and hold the whole media when printing.
8 Media cut groove Installed inside of Front cover.
Used to cut media straight.
9 Maintenance cover Used to prevent the user from touching the inner mechanical section.
Open/close in the following cases.
• When cleaning Cleaning wiper
• When cleaning circumference of Print head
• When replacing Cutter
It is normally closed.
10 Adjuster Used to install the printer horizontally.
11 Media holder plate Installed inside of Front cover.
By attaching Media holder plates to both sides of the media, media warpage can be
prevented to a degree.
12 Connector • Used to install Spectrophotometer (SPECTROVUE VM-10) to VJ-1624X.
• VJ-1624WX/1924WX is not equipped with Connector.
13 Waste fluid tank Used for collecting waste ink discharged from the printer.
No. Name Function
