MUTOH ValueJet VJ-1624X - Page 340

7 Troubleshooting VJ-1624X/1624WX/1924WX OPERATION MANUAL
340 7.3 The media is jammed
4. Raise Media loading lever.
5. Pull the media to your side, and cut the torn part with cutting tools such as a razor blade.
No. Name
1 Media loading lever
No. Name
1 Razor blade
2 Roll
1
