VJ-1624X/1624WX/1924WX OPERATION MANUAL Before using
3.3 Filling ink 75
• Insert High-capacity ink pack adapters all the way in Ink cartridge slots.
• When a High-capacity ink pack adapter is installed, "Ink Refill **%" is displayed on Operation
panel and ink replenishment starts.
• Initial filling takes about 6 minutes.
Ink filling operation and pause operation are repeated during the initial ink replenishment.
• When "100%" is displayed, the initial ink replenishment is complete.
• When the initial ink charge is complete, "SubTank Refill **%" is displayed on the operation
panel, and the printer starts filling the subtank.
• When 100% is displayed, the subtank ink replenishment is complete.
• After the subtank ink replenishment is complete, Media End is displayed on the operation panel.
• Comply strictly with the following during ink filling. If filling is interrupted, ink will
be lost when filling is resumed.
• Do not turn OFF the power of the printer.
• Do not unplug the power cord set of the printer.
• Do not open Front cover.
• Do not open Maintenance cover.
• Do not raise Media loading lever.
No. Name
1 High-capacity ink pack adapter
2 Ink cartridge slot K
3 Ink cartridge slot C
4 Ink cartridge slot M
5 Ink cartridge slot Y
To Next Page
