FP0 Hardware 6.2 Specifications
6-3Matsushita Electric Works (Europe) AG
6.2 Specifications
Performance Specifications
Primary Rated operating voltage 115/230V AC
Side
Operating voltage range 85 to 265V AC
Rated operating frequency 50/50Hz
Operating frequency range 40 to 70Hz
Inrush current <50A at 55C/131_F
Current consumption 145mA (at 230V and 0.7A output current)
Over voltage protection PROTECTED
Secondary Rated output voltage 24V DC
Side
Output voltage range 23.5V to 24.5V DC
Nominal output current 0.7A
Output current range 0 to 0.7A
Output ripple <60mVpp
Short circuit protected electronic, automatic restart mode
Over voltage protected Yes
Over load protected Yes (switch off at ~0.8A and more)
Holding time min. 20ms at 230V AC
General Specifications
Characteristics primary switched, temperature and current peak controlled
Ambient temperature 0C/32_F to +55C/131_F
Storage temperature –20C/–4_F to +70C/158_F
Ambient humidity 5 to 95% non condensing
Storage humidity 5 to 95% non condensing
Vibration resistance 10 to 55Hz, 1 cycle/min., double amplitude of 0.75mm, 10 min.
on 3 axes
Shock resistance 10g min., 4 times on 3 axes
Life time min. 7 years at nom. load, 25C/77_F ambient temperature, 20000h
at 55C/131_F with full load/continuous operation
Mounting DIN rail or FPO flat attachment plate
Size 90× 60× 30.4mm
Input connector AC side MC connector, 2 pin
Output connector DC connector, 6 pin, 3 pins for “+” and 3 pins for “–”
Status display LED (green) at the front side for the secondary voltage indica-
tion
Note
Before you turn the power on, see page 10 - 2.
