NAiS FP Series Hardware Manual

FP0 Hardware 1.2 Expansion Units
1-3Matsushita Electric Works (Europe) AG
1.2 Expansion Units
Expansion units provide digital and analog in–/outputs.
1.2.1 Expansion I/O Units
There are combined in–/output units, input units, and transistor output units. They are
either equipped with terminals or with MIL connectors.
Terminal type
8 points
Input: 4
Relay output: 4
16 points
FP0-E16RS
(
FP0-E8RS
)()
Input: 8
Relay output: 8
MIL type
Input: 8
Transistor output: 8
16 points 32 points
Input: 16
Transistor output: 16
NPN open collector: FP0-E16T
PNP open collector: FP0-E16P
NPN open collector: FP0-E32T
PNP open collector: FP0-E32P
()
()
8 inputs 16 inputs
FP0-E8X FP0-E16X
