NAiS FP Series - Intelligent Unit and Link Unit

FP0 HardwareOverview
1-4 Matsushita Electric Works (Europe) AG
MIL type, continued
NPN open collector: FP0-E8YT
PNP open collector: FP0-E8YP
NPN open collector: FP0-E16YT
PNP open collector: FP0-E16YP
8 transistor outputs 16 transistor outputs
1.2.2 Intelligent Unit and Link Unit
The analog unit provides 2 inputs and 1 output.
Analog I/O unit
Input: 2 channels
Output: 1 channel
FP0-A21
()
The FP0 I/O Link Unit works as the slave station of a remote I/O system. The FP0 I/O
Link Unit exchanges I/O information with the master unit.
FP0 I/O Link Unit
FP0–IOL
Input: 32 points
Output: 32 points
()
