NAiS FP Series Hardware Manual

FP0 Hardware 2.2 Specifications
2-5Matsushita Electric Works (Europe) AG
2.2 Specifications
2.2.1 General Specifications
Item Description
Ambient humidity
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
30% to 85% RH (non-condensing)
Ambient temperature
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
0°C to +55°C/32°F to +131°F
Allowed C10/C14
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
5ms at 21.6V, 10ms at 24V
momentary power
off time
C16/C32/T32
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
10ms at 21.6V, 10ms at 24V
Breakdown voltage
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
500V AC for 1 minute between I/O terminal and power supply/ground terminal
1500V AC for 1 minute between I/O terminal and power supply/ground
terminal (relay output type only)
Insulation resistance
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
min. 100MΩ (measured with a 500V DC megger)
between I/O terminal and ground terminal
Noise immunity
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
1,000Vp-p with pulse widths 50ns and 1µs (based on in-house measurements)
Operating condition
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Free from corrosive gases and excessive dust
Operating voltage range
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
21.6V to 26.4V DC
Rated operating voltage
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
24V DC
Rated current consumption
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
300mA or less (see page 2-6)
Shock resistance
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Shock of 98m/s
2
or more, 4 times on 3 axes
Storage humidity
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
30% to 85% RH (non-condensing)
Storage temperature
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
–20°C to +70°C/–4°F to +158°F
Vibration resistance
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
10Hz to 55Hz, 1 cycle/min: double amplitude of 0.75mm/ 0.030in., 10min. on 3
axes
2.2.2 Weight
Type Weight
C10RS/C10CRS
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 100g/3.53oz
C14RS/C14CRS
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 105g/3.70oz
C16T/C16CT/C16P/C16CP
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 85g/3.00oz
C32T/C32CT/C32P/C32CP
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 115g/4.06oz
T32CP
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 130g/4.59oz.
E8RS/E8RM
ÁÁÁÁÁÁÁÁÁ
approx. 90g/3.17oz
E8X/E8YT/E8YP
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 65g/2.29oz
E16RS/E16RM
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 105g/3.70oz
E16T/E16P/E16X/E16YT/E16YP
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 70g/2.47oz
E32T/E32P
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
approx. 85g/3.00oz
