NAiS FP Series Hardware Manual

FP0 HardwareOverview
1-2 Matsushita Electric Works (Europe) AG
1.1 Control Units
The in–/output units provide different amount of points, are equipped with/without
RS232C port and with terminals or MIL connectors.
Terminal type
10 points
FP0-C10RS
Input: 6
Relay output: 4
()
10 points with
RS232C
FP0-C10CRS
FP0-C14CRS
14 points with
RS232C port
FP0-C14RS
14 points
Input: 8
Relay output: 6
()
MIL type
Input: 8
Transistor output: 8
16 points
NPN open collector: FP0-C16T
PNP open collector: FP0-C16P
Input: 8
Transistor output: 8
NPN open collector: FP0-C16CT
PNP open collector: FP0-C16CP
16 points with RS232C port
()
()
PNP open collector: FP0-T32CP
32 points with RS232C port
Input: 16
Transistor output: 16
NPN open collector: FP0-C32T
PNP open collector: FP0-C32P
32 points
Input: 16
Transistor output: 16
(
)
()
32 points with
RS232C port
