FP0 Hardware 5.3 Specifications
5-5Matsushita Electric Works (Europe) AG
5.3 Specifications
5.3.1 General Specifications
Item Specification
Rated supply voltage 24V DC
Supply voltage range 21.6 to 26.4V DC
Consumption current I/O Link unit: max. 40mA / 24V DC
Control unit: max. 30mA / 24V DC
Allowed momentary
power off time
10ms (max)
Ambient temperature 0_C to 55_C (32_F to 131_F)
Storage temperature –20_C to 70_C (–4_F to 158_F)
Ambient humidity 30% to 85% RH (non–condensing)
Storage humidity 30% to 85% RH (non–condensing)
Breakdown voltage RS485 terminals ←→ Power supply / function earth terminals: AC500V 1minute
Insulation resistance RS485 terminals ← → Power supply / function earth terminals: min. 100MΩ (measured
with a 500V DC megger)
Vibration resistance 10Hz to 55Hz, 1 cycle/min.: double amplitude 0.75mm (0.03in.),
10 minutes on 3 axes.
Shock resistance Minimum 98m/s
2
, 4 times on 3 axes.
Noise immunity 1000Vp–p with pulse widths 50ns and 1µs (based on in–house measurements)
Operating condition Free from corrosive gases and excessive dust
Weight Approx. 85g
5.3.2 Performance Specifications
Item Specifications
Communication method Two–line, half–duplex
Synchronous method Asynchronization system
Communication rate 0.5Mbps
Interface RS485
Communication error check method CRC (Cyclic Redundancy Check)
I/O map of FP0 I/O Link Unit 32X / 32Y
