FP0 HardwareSelf-Diagnostic and Troubleshooting
11-6 Matsushita Electric Works (Europe) AG
11.2.4 Diagnosing Output Malfunction
Check of output condition (output indicator LEDs are ON)
Check if the power is properly supplied to the loads.
If the power is properly supplied to the load, there is probably an abnormality in
the load. Check the load again.
If the power is not supplied to the load, there is probably an abnormality in the
FP0’s output circuit. Please contact your dealer.
Check the wiring of the loads.
<Procedure 1 >
<Procedure 2>
Check of output condition (output indicator LEDs are OFF)
Monitor the output condition using a programming tool.
Forcing ON the output using a programming tool.
If the output indicator LED is turned ON, go to input condition check.
If the output indicator LED remains OFF, there is probably an abnormality in the
FP0’s output circuit. Please contact your dealer.
<Procedure 1 >
<Procedure 2>
If the output monitored is turned ON, there is probably a duplicated output error.
Check of input condition (input indicator LEDs are OFF)
Check that the power is properly supplied to the input terminals.
If the power is properly supplied to the input terminal, there is probably an abnor-
mality in the FP0’s input circuit. Please contact your dealer.
If the power is not properly supplied to the input terminal, there is probably an
abnormality in the input device or input power supply. Check the input device and
input power supply.
Check the wiring of the input devices.
<Procedure 1 >
<Procedure 2>
