NAiS FP Series Hardware Manual

FP0 HardwareControl Units
2-6 Matsushita Electric Works (Europe) AG
2.2.3 Current Consumed by the Control Unit
The current consumed at the power supply connector of the control unit is the sum of
the current consumed by of the various units being used.
Type
Current consumption
(at 24V DC)
Control unit C10RS, C10CRS
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
100mA or less
C14RS, C14CRS
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
100mA or less
C16T, C16CT, C16P, C16CP
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
40mA or less
C32T, C32CT, C32P, C32CP, T32CP
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
60mA or less
Expansion I/O unit E8X
ÁÁÁÁÁÁÁÁÁÁ
10mA or less
E8YT, E8YP
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
15mA or less
E8RS, E16RS, E16X
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
20mA or less
E16YT, E16YP, E16T, E16P
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
25mA or less
E32T, E32P
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
40mA or less
Analog I/O unit A21
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
20mA or less
FP Programmer II Ver. 2 (AFP1114V2)
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
50mA or less
C-NET adapter S2 type (AFP15402)
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
50mA or less
Current consumed when the unit requires an external power supply
With a relay output type of expansion I/O unit and an analog I/O unit, it is necessary to
provide a power supply to drive internal circuits.
Type
Current consumption
(at 24V DC)
Expansion I/O unit E8RS
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
50mA
E16RS
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
100mA
Analog I/O unit A21
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
100mA
