NAiS FP Series Hardware Manual

FP0 Hardware 3.4 Pin Layouts
3-15Matsushita Electric Works (Europe) AG
3.4 Pin Layouts
3.4.1 E8RS
X20
X23
COM
Y20
Y23
COM
COM
X20
X21
(NC)
(NC)
X22
X23
(NC)
(NC)
Inputs
Outputs
(see notes)
COM
Y20
Y21
(NC)
(NC)
Y22
Y23
(NC)
(NC)
Power
supply
Load
Load
Load
Load
Y0–3
X0–3
Notes
Either positive or negative polarity is possible for the input
voltage supply.
The I/O number given above is the I/O number when the
expansion I/O unit is installed as the first expansion unit.
The I/O numbers for the expansion I/O units will differ
depending on the location where they are installed
(see page 7 - 4).
