NAiS FP Series Hardware Manual

FP0 Hardware D.8 FP0 Slim Type Mounting Plate
D-9Matsushita Electric Works (Europe) AG
D.8 FP0 Slim Type Mounting Plate
25.0/0.9844/0.157
60.0/2.362
90.0/3.543
10.0/0.394
6.0/0.236
dir. 10.0/0.394 dir. 5.0/0.197
3.5/0.138
2.5/0.098
(unit: mm/in.) (unit: mm/in.)
Figure 1 : One plate
90.0/3.543
100/3.937
60.0/2.362
dir. 10.0/0.394
25.0/
0.984
60.0/2.362
dir. 5.0/2.362
75.0/2.953
dir. 5.0/0.197
25.0/
0.984
25.0/
0.984
After joining all of the FP0 slim type mounting
plates to be connected, tighten the corner
screws.
(unit: mm/in.)
Figure 2 : Four plates in series
Figure 3 : Mounting hole dimensions
