NAiS FP Series Hardware Manual

FP0 Hardware 2.2 Specifications
2-11Matsushita Electric Works (Europe) AG
Notes
1) When using the RS232C port for communication,
retransmission is recommended.
The driver IC for the RS232C port conforms completely to
EIA/TIA-232E and CCITT V28 standards.
2) The combinations 1 phase  2 channels and 2 phases  1
channel are also possible for the high-speed counter.
3) For details and limitations on the high-speed counter, pulse
output, and PWM output functions. See FP0 Programming
Manual.
4) The max. counting speed (10kHz) is the counting speed with a
rated input voltage of 24V DC and an ambient temperature of
25°C/77°F. The counting speed (frequency) will decrease
depending on the voltage and temperature.
5) If the unit is equipped with both reset inputs X0 and X1, X2
serves as the reset input for X1. If X3 and X4 are used, X5
serves as the reset input for X4.
6) With control unit’s CPU that is Ver.2.0 or a subsequent
version, the frequency will be 0.15Hz to 1kHz.
2.2.5 Input Specifications
Item Description
Insulation method
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
optical coupler
Rated input voltage
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
24V DC
Rated input current
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
approx. 4.3mA (at 24V DC)
Input impedance
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
approx. 5.6kΩ
Operating voltage range
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
21.6 to 26.4V DC
Input points per
common
C10RS,
C10CRS
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
6 points/common
(see note 1)
C14RS,
C14CRS
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
8 points/common
C16T, C16CT,
C16P, C16CP
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
8 points/common
C32T, C32CT,
C32P, C32CP,
T32CP
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
16 points/common
ON voltage/ON current
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
19.2V or less/3mA or less
OFF voltage/OFF current
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
2.4V or more/1mA or more
Response time
(at 24V DC and
25°C/66°F)
OFF ↔ ON
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
50µs or less (at X0, X1) (see note 2)
100µs or less (at X2 to X5) (see note 2)
2ms or less (at X6 to XF)
25 C/66 F)
ON ↔ OFF
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
the same as above
Operating mode indicator
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
LED
Notes
1) Either positive or negative polarity is possible for the input
voltage supply.
