FP0 Hardware C.1 Special Data Registers
C-9Matsushita Electric Works (Europe) AG
Addresses Description
T32CP Other Types
DT90060 DT9060 Process
number:
0 to 15
Step ladder process
Indicates the startup condition of the step ladder process. When the
proccess starts up, the bit corresponding to the process number turns
DT90061 DT9061 Process
number:
16 to 31
15 11 7 3 0
on 1.
Monitor using binary display.
DT90062 DT9062 Process
number:
32 to 47
DT9060
15 11 7 3 0
(Bit No.)
15 11 7 3 0 (Process No.)
DT90063 DT9063 Process
number:
48 to 63
0: notexecuting
1: executing
DT90064 DT9064 Process
number:
64 to 79
A programming tool can be used to write data.
DT90065 DT9065 Process
number:
80 to 95
DT90066 DT9066 Process
number:
96 to 111
DT90067 DT9067 Process
number:
112 to 127
DT90104 DT9104 High-speed counter elapsed value area for ch2
The elapsed value (24bit data) for the highspeed counter is stored here. Each time
DT90105 DT9105
the ED instruction is executed, the elapsed value for the highspeed counter is auto-
matically transferred to the special registers DT9104 and DT9105.
The value can be written by executing a DMV (F1) instruction.
DT90106 DT9106 High-speed counter target value area for ch2
The target value (24bit data) of the highspeed counter specified by the highspeed
counter instruction is stored here.
DT90107 DT9107
counter instruction is stored here.
Target values have been preset for the various instructions, to be used when the
highspeed counter related instruction F166 to F170 is executed. These preset val-
ues can only be read, and cannot be written.
DT90108 DT9108 High-speed counter elapsed value area for ch3
The elapsed value (24bit data) for the highspeed counter is stored here. Each time
DT90109 DT9109
the ED instruction is executed, the elapsed value for the highspeed counter is auto-
matically transferred to the special registers DT9108 and DT9109.
The value can be written by executing a DMV (F1) instruction.
DT90110 DT9110 High-speed counter target value area for ch3
The target value (24bit data) of the highspeed counter specified by the highspeed
counter instruction is stored here.
DT90111 DT9111
counter instruction is stored here.
Target values have been preset for the various instructions, to be used when the
highspeed counter related instruction F166 to F170 is executed. These preset val-
ues can only be read, and cannot be written.
