FP0 Hardware
Expansion I/O Units
3-10
Matsushita Electric Works (Europe) AG
PNP Open Collector T
ype
FP0-E16P/E32PT
X20
X2n
COM
Y20
(+)
Y2n
Load
Load
5.6k
Ω
5.6k
Ω
Internal
circuit
Input
side
Output side
Internal
circuit
Internal
circuit
Internal
circuit
(
–
)
24V DC
1k
Ω
1k
Ω
24V DC
(see
notes)
Notes
Either
positive or negative polarity is possible for the input
voltage supply
.
The I/O number given above is the I/O number when the
expansion I/O unit is installed as the first expansion unit
(
see page
7
-
4
).
52
54
